PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules
  • PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules
  • PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules

PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules

Plaats van herkomst Jiangsu, China
Merknaam AKS
Certificering CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Modelnummer AH7G
Productdetails
Productnaam:
MWT Volledige Zwarte Zonnepanles
Modelnummer:
AH7G
Celgrootte:
144 (24x6-)/10BB Mono/helft-Cel
Comité Efficiency:
21.7%
De Dimensie van de installatiemodule:
2277mm*1133mm*35mm
Merknaam:
Sunport
Type:
PERC, Halve Cel
Schakelaar:
MC4
Materiaal:
Monocrystalline Silicium
Garantie:
15 jaar
Gewicht:
27.5kg
Hoog licht:

De Zonnepanelen van AH7G Sunport

,

Dunne Flexibele Zonnepanelenpv Modules

,

10BB dunne Flexibele Zonnepanelen

Betaling & het Verschepen Termijnen
Min. bestelaantal
30
Prijs
$0.17~0.20/Watts
Verpakking Details
Pallet
Levertijd
Om worden onderhandeld
Betalingscondities
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Levering vermogen
200000 Watts/Watts per Week
Productbeschrijving

Sunport AH7G 10BB Power High Low Price Good Price The Solar Panels PV Modules

10BB half-cut cell technology

New circuit design, lower internal current, lower Rs loss Ga dopped wafer, attenuation≤2% (1st year) / ≤0.45% (Linear)

Industry leading high yield

Bifacial PERC cell technology, 5%-25% more yield depends on different conditions

Excellent Anti-PID performance

3 times of industry standard Anti-PID test

Wider application

No water-permeability and high wear-resistance, can be widely used in high-humid, windy and dusty area

IP68 junction box

High waterproof level



Electrical Characteristics at Standard Test Conditions(STC)
Spec/Model
Unit
SSD535
AH7G
SSD540
AH7G
SSD545
AH7G
SSD550
AH7G
SSD555
AH7G
SSD560
AH7G
Max-Power(Pm)
W
535
540
545
550
555
560
Power Tolerance
W
0~±5
Max-Power Voltage(Vm)
V
41.5
41.66
41.80
41.95
42.10
42.25
Max-Power Current(lm)
A
12.90
12.97
13.04
13.12
13.20
13.27
Open-Circuit Voltage(Voc)
V
49.50
49.63
49.75
49.90
50.05
50.20
Short-Circuit Current(lsc)
A
13.63
13.67
13.74
13.77
13.82
13.86
Module Efficiency(qm)
%
20.7
20.9
21.1
21.3
21.5
21.7
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 0PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 1
TECHNOLOGY COMPARISON
Compared with conventional module, MWT modules reduce 3% shaded area with no busbars. MWT module technology replaces string ribbon by conductive back sheet, abandoning strain, micro-crack and results power degradation, greatly improving stability and reliability.
— Structural Feature —
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 2
MWT
Positive and negative electrodes are both on the rear side of solar cell
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 3
Conventional
Positive and negative electrodes are located on opposite sides of the cell
— Cell Structure —
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 4
MWT
Busbar-free design exhibits higher power output by decreasing shading area up to 3 %
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 5
Conventional
Conventional design covers more cell surface from the main busbars, therefore the power output is limited
— Module Encapsulation —
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 6
Replace conventional soldering with conductive foil and 2D encapsulation structure
PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 7
Conventional Cells connected by string ribbons



PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 8



PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 9PV van de Zonnepanelen10bb Dunne Flexibele Zonnepanelen van AH7G Sunport Modules 10



FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc


Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
